Benefits and Performances

01 High-Accuracy Data Capture

The AA15 delivers 15 mm linear accuracy on long-range scans up to 150 meters using CHCNAV's patented tilted-prism technology. Its precision ensures reliable data for complex projects, such as corridor mapping, where high-density point clouds are essential.
02 Extended Range and Coverage

With a maximum range of 1800 meters and a flying height of up to 700 meters, the AA15 is capable of large-scale area coverage with minimal point loss for corridor mapping applications such as highways, railroads, and pipeline inspections.
03 Exceptional Vegetation Penetration

The AA15 excels in penetrating dense vegetation with its advanced multi-target capability, supporting up to 16 returns per laser pulse. It enables the detection of more ground points, ensuring comprehensive data collection in forested areas and improving the accuracy of terrain models.
04 Wide Platform Compatibility

The AA15’s lightweight design (2.5 kg) and CHCNAV's unified AlphaPort interface allow for quick integration with various airborne platforms, including UAVs, small aircraft, and helicopters.
05 High-Density Point Clouds

Capturing 2 million points per second, the AA15 is perfect for applications requiring high-density point clouds, such as power line inspections, road surveys, and urban mapping.
06 Advanced Imaging Options

The AA15 supports a range of external cameras, including CHCNAV's 45 MP and 61 MP full-frame calibrated cameras and a 130 MP half-frame oblique camera. The integration of high-resolution imagery with LiDAR data enhances the quality of 3D models and texture mapping.
07 Comprehensive Ecosystem

The AA15 is part of CHCNAV's complete airborne mapping solution, which includes the SmartGo app for automated reality capture and mission monitoring, and CoPre and CoProcess software for streamlined post-processing and feature extraction.
08 Rugged and Reliable

Designed to withstand challenging environments, the AA15 operates in temperatures ranging from -20°C to +50°C and is IP64-rated for dust and water resistance. Its robust construction ensures reliable performance in a variety of field conditions.

Detailed Specifications

Specifications

Resources

Comparison

CHCNAV AlphaAir 15

Premium Airborne LiDAR Solution
Laser Scanner
- Range : 1800 m
- Scanning rate : 2,000,000 pulses/sec
- Field of view : 75°
- Returns : Up to 16
Positioning
- GNSS : Fulll GNSS
- IMU : 600 Hz
- Precision max. : <5 cm H / <5 cm V
Sensors
- Camera : Optional external camera
Download

AA15_DS_EN.pdf

3.76 MB

Download

AA15_DS_FR.pdf

3.75 MB

Download

AA15_DS_ES.pdf

3.75 MB

Download
- CHCNAV AlphaAir 15

  Premium Airborne LiDAR Solution
  - Laser Scanner
    - Range
      :
      1800 m
    - Scanning rate
      :
      2,000,000 pulses/sec
    - Field of view
      :
      75°
    - Returns
      :
      Up to 16
  - Positioning
    - GNSS
      :
      Fulll GNSS
    - IMU
      :
      600 Hz
    - Precision max.
      :
      <5 cm H / <5 cm V
  - Sensors
    - Camera
      :
      Optional external camera
- CHCNAV AlphaAir 10

  Professional Airborne LiDAR+RGB System
  - Laser Scanner
    - Range
      :
      800 m
    - Scanning rate
      :
      500,000 pulses/sec
    - Field of view
      :
      75°
    - Returns
      :
      Up to 8
  - Imaging
    - Resolution
      :
      45 MP
    - Focal length
      :
      21 mm
  - Positioning
    - GNSS
      :
      Full GNSS
    - IMU
      :
      500 Hz
    - Precision max.
      :
      < 5 cm H / < 5 cm V
  - Sensors
    - Camera
      :
      Optional external camera

Explore our FAQs

1. Can the AA15 be used on different airborne platforms?

Yes, the AA15’s lightweight design and CHCNAV Alphaport interface allow for quick integration with UAVs, RPAS, manned aircraft, and helicopters.
2. What is the maximum operational range of the AA15?

The AA15 has a maximum range of 1800 meters, making it suitable for large-scale area coverage, including corridor mapping and urban planning.
3. What software solutions are compatible with the AA15?

The AA15 integrates with CHCNAV’s SmartGo app for mission monitoring and CoPre and CoProcess software for post-processing, ensuring efficient data workflows.
4. How is data stored and transferred from the AA15?

The AA15 features 512 GB of onboard storage (with an optional 1 TB upgrade) and supports data transfer via Ethernet, ensuring efficient data management.
